CBROM
CBROM — утилита для редактирования не UEFI BIOS от AWARD а ныне PHOENIX, так как это теперь одна компания. Программа работает в командной строке Windows! Из под чистого DOS, работать не будет!
CBROM195.EXE V1.95 Phoenix Technologies 2001-2007
Syntax:
C:…\CBROM195.EXE InputFile [/other] [8000:0] [RomFile|Release|Extract]
C:…\CBROM195.EXE InputFile [/D|logo|vga….] [RomFile|Release|Extract][checksum]
InputFile : System BIOS to be added with Option ROMs
/D : For display all combined ROMs informations in BIOS
/epa|epa1-7 : Add EPA LOGO BitMap to System BIOS
/logo|logo1-7: Add OEM LOGO BitMap to System BIOS
/osb_logo|osb_logo1-7: Add OSB LOGO BitMap to System BIOS
/osb_bmp|osb_bmp1-7: Add OSB CPU BitMap to System BIOS
/oem0-7 : Add special OEM ROM to System BIOS
/err : Return error code after executed
/btvga : Add VGA ROM to Boot Rom Block Area.
/isa : Add ISA BIOS ROM to System BIOS.(/isa Filename [xxxx:0])
/vga, /logo, /pci, /awdflash, /cpucode, /epa, /acpitbl, /vsa, /hpm
/hpc, /fnt0 — 5, /ros, /nnoprom, /mib, /group0-5, /NoCompress
/jpeg|jpeg1-3: Add JPEG LOGO to System BIOS
/gif0-3 : Add GIF LOGO to System BIOS
/rpb : Add RPB ROM to System BIOS
/ver : Add version table of source code to System BIOS
/jpeg_eng : Add JPEG engine to System BIOS
/nc_cpucode : Add non-compress cpu code
/srom0-4 : Add software ROM
/setup0-1 : Add setup ROM
/biosf0-9 : Add BIOS feature ROM
/GV3 : Add GV3 ROM
/CALS : Calculate ROM Compress size but not add ROM in BIN file
/efi0-9 : Add EFI feature ROM
/minit : Add Intel memory module
/NVMM : Add nVIDIA memory module
/mpdrv : Add TPM MP driver
/madrv : Add TPM MA driver
/tcgsmi : Add TCG 32 bit smi code
/flshcode : Add flash part code
/SLPKey : Add SLP 2.0 Public Key
/SLPMarker : Add SLP 2.0 Marker
/NVPMU : Add PMU ROM
/BTMEM : Add memsizing module in bootblock
/HOLE0-7 : Add option ROM in hole
/htinit : Add AMD HT init module
/1pe32 : Add type 1 PE32 module in mainblock
/1pe32b : Add type 1 PE32 module in bootblock
/2pe32 : Add type 2 PE32 module in mainblock
/2pe32b : Add type 2 PE32 module in bootblock
/3pe32 : Add type 3 PE32 module in mainblock
/3pe32b : Add type 3 PE32 module in bootblock
/4pe32 : Add type 4 PE32 module in mainblock
/4pe32b : Add type 4 PE32 module in bootblock
/ACPIModule : Add ACPI module, such as SSDT module.
/SMI32 : Add 32-bit SMI module.
/SMIAP : Add application SMI module.
RomFile : File name of option ROM to add-in
noreserve : No reserve system color for BMP logo
Release : Release option ROM in current system BIOS
Extract : Extract option ROM to File in current system BIOS
checksum : Add checksum for Hole0~7 module at end of the hole.
/BOI UseDHCP Server_IP Static_IP Net_Mask Gate_Way DNS UseProxy
Proxy_IP ProxyPort: Setting Boot On Internet parameters.
/BOI : Show the Boot On Internet parameters.
Example 1 for setting the BOI parameters:
cbrom /boi 1 134.122.168.184 134.122.106.113 255.255.255.0
134.122.106.5 134.122.101.90 0 134.122.106.105 32896
Example 2 for setting the BOI parameters:
cbrom /boi 1, 134.122.168.184, , , , 134.122.101.90 0, ,32896
Example 3 for show the BOI parameters:
cbrom /boi
/TopHole:address : Add a module at fixed address.
Example: cbrom /TopHole:FFFD0000 xxx.bin
/osb_logo_gui|osb_logo1-7_gui: Add GUI OSB LOGO BitMap to System BIOS
/osb_bmp_gui|osb_bmp1-7_gui: Add GUI OSB CPU BitMap to System BIOS
